EP506 - 900mm Electric Griddle Static Oven Range
Product Features
- 900mm electric griddle oven range
- 2/1 GN electric static oven
- 12kW heating elements
- Separate left and right heat zones
- Heavy-duty stainless steel finish
- Heavy-duty reinforced control knobs
- Drop down door with welded frame
- Fully welded and vitreous enamelled oven liner
- Cool touch stainless steel door handle
- Adjustable feet and 2 additional rollers
- Easy clean, installation and service
Cooktop
• 2.4kW open radiant elements in heavy-duty welded element frames
• Stainless steel spill trays
• Hot plate elements with machine finished 8mm steel plate (optional extra)
• 12mm thick mild steel griddle plates
• 2.5mm 304 stainless steel griddle splash guards
• Aluminised steel internal construction
Griddle sections are standard on RH side. Available on LH side or centre to order.
Oven
• Fully welded and vitreous enamelled oven liner
• GN 2/1 capacity with 4 position racking
• Heavy-duty easy remove heavy wire chrome rack supports
• Cast iron even heat oven sole plate
• 6.5kW heating elements
• Drop down door
• 0.9mm 304 stainless steel door outer
• 1.0mm vitreous enamelled door inner
• High density fibreglass insulated
• Supplied with two chrome wire oven racks
Cleaning and Servicing
• All models with easy clean stainless steel external finish
• Plate is finished front and rear with overlap construction to remove cleaning traps
• Control service through front of unit
• Warranty : 12 months (5-year cabinet parts, 2 year wash pump parts and labour)
Dimensions
W: 900mm D: 812mm H: 1085mm
Volume: 1.04m3
Packed Weight: 218kg
OPTIONAL GRIDDLE PLATE SURFACES – RIBBED
PE912R3* -900mm x 12mm Griddle plate – ribbed 300mm RH
PE912R3M* -900mm x 12mm Griddle plate – ribbed 300mm M
PE912R5* -900mm x 12mm Griddle plate – ribbed 450mm RH
PE912R6* -900mm x 12mm Griddle plate – ribbed 600mm RH
PE912R9* -900mm x 12mm Griddle plate – ribbed full
OPTIONAL EXTRAS – ELECTRIC GRIDDLE / GRIDDLE OVENS
228566-Griddle scraper tool
228567-Smooth plate scraper blades (pack of 5 blades)
233817-Ribbed plate scraper blade (individual blade)
228807-Mobile castor kit (set of 2 lockable castors)
